| INCUBATOR |
NB-206CXL |
NB-206CXXL |
| Temp. range |
Ambient +5℃ to 60℃ |
Ambient +5℃ to 60℃ |
| Temp. accuracy |
±1℃ at 37℃ |
±1℃ at 37℃ |
| Humidity |
≥70% at 37℃ |
≥70% at 37℃ |
| CO2 range |
0% to 20% |
0% to 20% |
| CO2 accuracy |
±0.3% at 5% at 37℃ |
±0.3% at 5% at 37℃ |
| CO2 sensor |
IR CO2 sensor |
IR CO2 sensor |
| CO2 inlet pressure |
0.7 ~ 1 bar |
0.7 ~ 1 bar |
| Outer door |
Silicon packing magnet door |
Silicon packing magnet door |
| Inner door |
Each inner door of 3 Shelves |
Each inner door of 3 Shelves |
| Display |
LED Display |
LED Display |
| Jacket type |
Air jacket type (6 sides heating) |
Air jacket type (6 sides heating) |
| Filter |
Anti-Bacterial Hepa filter |
Anti-Bacterial Hepa filter |
| Sterilization |
U.V 4Wx1ea |
U.V 4Wx1ea |
| Chamber volume |
650 liter |
850 liter |
| Shelves |
3ea |
3ea |
| Chamber dimensions |
700(W)x650(D)x1430(H)mm |
700(W)x800(D)x1530(H) mm |
| Each compartment Dimension |
Compartment 1(Bottom): 700(W)x650(D)x430(H) mm
Compartment 2, 3 (Middle, Top): 700(W)x650(D)x380(H) mm |
700(W)x800(D)x410(H) mm |
| Overall dimensions |
820(W)x780(D)x1740(H) mm |
820(W)x920(D)x1840(H) mm |
| Weight |
323kg |
393kg |
| Power |
110/220V, 50/60Hz |
110/220V, 50/60Hz |
| SHAKER |
|
|
| Shaking motion |
Orbital |
Orbital |
| Speed range |
30 to 200 rpm |
30 to 250 rpm |
| Speed accuracy |
±1rpm |
±1rpm |
| Speed increment |
1rpm |
1rpm |
| Time range |
Continuous or up to 47h 59mins |
Continuous or up to 47h 59mins |
| Time accuracy |
±1% |
±1% |
| Time increment |
1 minute |
1 minute |
| Motor |
Plate type BL/DC Motor |
Plate type BL/DC Motor |
| Drive system |
Beltless direct drive |
Beltless direct drive |
| Orbit diameter |
25mm |
25mm |
| Platform size |
520(W)x520(D) mm |
520(W)x520(D) mm |
| Dimension |
465(W)x540(D)x125(H) mm |
465(W)x540(D)x125(H) mm |
